Choose an industrial silent diesel generator by matching its duty rating and configuration to the loads it must supply, the site conditions and the project requirements. Start with a load list and operating schedule, then confirm voltage, frequency, starting performance, noise criteria and installation needs with the supplier and project engineer.
This guide focuses on application and sizing inputs. Use the separate supplier verification checklist to review engine identification, supporting documents, acceptance evidence and warranty terms.
1. Describe how the generator will operate
Tell the supplier whether the unit is intended for emergency backup, regular operation or another defined duty. Include expected operating hours, outage duration, load variation and any planned expansion. Ask for the manufacturer’s rating definition and operating limits for the proposed model; compare quotations using the same duty basis.
2. Build a load list before choosing a power label
- List the equipment to be supplied and its electrical nameplate data.
- Identify which loads run together and which can be connected in stages.
- Record motor starting methods and available starting-current data.
- Identify UPS systems, variable-speed drives and other loads that require separate assessment.
- State the voltage and frequency variation the connected equipment can tolerate.
Running demand alone does not establish starting performance. Cummins’ T-030 application manual discusses how motor starting affects generator voltage and how starting methods influence the required capacity. Ask the project engineer to evaluate the proposed load sequence and transient performance instead of relying on a universal percentage margin.
3. Keep kW, kVA and power factor explicit
kW describes real power and kVA describes apparent power. Their relationship is kW = kVA × power factor. For example, at a stated power factor of 0.8, 250kVA corresponds to 200kW. This arithmetic does not prove that a particular genset can start a particular motor or supply every 200kW load profile.
Confirm the model’s output rating at the required voltage and frequency and under the specified site conditions. Keep the chosen power factor and rating category visible when comparing datasheets.
4. Confirm the electrical and control configuration
Record voltage, frequency, phase, earthing arrangement and the required connection to the site distribution system. Identify whether the project needs an automatic transfer switch, remote monitoring or operation with other generator sets. Ask the supplier to state which functions and accessories are included and which require additional equipment.
Review the proposed controller, protection devices, wiring drawings and operating sequence with the project engineer before production. Specify any interface requirements for the existing installation.
5. Give the supplier the actual site conditions
Cummins’ Power Suite includes GenSize for recommendations based on loads and project parameters, and GenCalc tools covering ventilation, exhaust back pressure and other installation calculations. These resources illustrate why the site and load details belong in the enquiry.
- Provide the destination, installation location, ambient temperature and altitude.
- Describe available space, service access and the intended enclosure arrangement.
- State fuel storage and operating-duration requirements.
- Identify site-specific noise criteria and the required measurement conditions.
- Ask the responsible project adviser to confirm applicable local requirements.
6. Confirm noise performance for the quoted configuration
The word “silent” is not a complete acceptance specification. Ask for a dB(A) value with test distance, operating load, test setting and enclosure configuration. Confirm that the supporting report applies to the offered package and agree how the completed installation will be assessed.
A practical technical enquiry checklist
Send the following information together so the supplier can review one consistent project brief:
- Application and operating duty.
- Load list, simultaneous demand and motor starting information.
- Required kW or kVA, if already established by the project engineer.
- Voltage, frequency and phase.
- Site conditions and installation constraints.
- Noise requirement and measurement conditions.
- Required controls, ATS, accessories and documentation.
- Quantity, delivery destination and requested delivery schedule.
Frequently asked questions
Is a 200kW generator suitable for every 200kW industrial load?
Suitability depends on the duty rating, load characteristics, starting requirements and site conditions. Review the complete load profile against the proposed generator’s technical data before confirming the selection.
Should I automatically add 20–30% to my running load?
Use a project-specific assessment. Starting method, load sequence and acceptable voltage or frequency dip can change the selection. A fixed percentage alone does not establish that the generator will meet the application requirements.
What should I do if I do not have a complete load list?
Collect equipment names, nameplate photographs, operating schedules and available electrical drawings. Send those details with the enquiry and identify any missing information that the supplier or project engineer needs to confirm.
Review a configuration or request a quote
See the GoCommins 200kW / 250kVA configuration, browse the generator product catalogue, or send your project requirements. Confirm the final selection and configuration against the quotation and technical datasheet.
